Renault Laguna Gt Introduces Active Drive Chassis

Stylish, expressive Renault Laguna GT introduces the new Active Drive chassis with four-wheel steering (4WS), developed jointly by Renault and Renault Sport Technologies to yield the ultimate in driving pleasure, as regards handling, response and precision. Its sporty calling is further enhanced by the availability of two exclusive, high-performance engines (180hp/131kW and 205hp/150kW).

The Active Drive chassis with four-wheel steering also excels in active safety, both under difficult braking conditions (with good control over asymmetrical grip, and ESP matched to sporty driving styles), and during avoidance manoeuvres at speed. The Active Drive chassis with four-wheel steering makes Renault Laguna GT exceptionally easy to handle in town and superbly agile on winding roads. At speeds of less than 60kphh, the rear wheels turn in the opposite direction to the front wheels, up to an angle of 3.5°. This brings two advantages: a smaller turning circle, for easy manoeuvring; and smaller steering wheel angles thanks to the more direct, specially calibrated steering.

With front wheels and rear wheels turning in opposite directions, the car effectively pivots, which means smaller steering angles are needed for the same turning effect. Because steering is moredirect, with less need for wide steering wheel angles, the impression of manoeuvrability and agility is greatly enhanced. For any given bend profile, the driver will need less action on the steering wheel. This makes for more effective avoidance, with the car seeming to weave effortlessly around obstacles.

The Active Drive chassis with four wheel steering also implements electronic control of vehicle dynamics. A sensor on the steering column sends steering wheel angle information via the CAN network to the 4WD control unit, located behind the rear axle. The 4WD control unit also inputs vehicle speed from the ESP/ABS unit. And it tracks steering wheel angle information to detect sharp steering wheel movements symptomatic of a sports driving style or avoidance situation. All these parameters are analysed to determine the required rear-wheel turn angle, which is implemented by means of an electric actuator on the rear axle. Dynamic vehicle behaviour is precisely modelled to set the ideal vehicle trajectory at each instant, on the basis of the driver's input and the actual situation of the vehicle.
