Read more [+]inci Aku NanoGold Start-Stop EFB has been specially designed for top segment and standard Start-Stop vehicles. In addition to its reinforced high-quality plates, it provides maintenance free extra long-life and extra performance even for new generation vehicles with high electricity consumption thanks to its special paste formula with Nano Crystal Technology.
What is Start-Stop Technology? Start-Stop system automatically shuts down the engine while your vehicle is idle during heavy traffic or at traffic lights and then restarts the engine when the driver engages the clutch, thus helping to prevent loss of energy.
Micro-hybrid in other words Start-Stop is a technology offering great advantage in urban traffic like:
- Fuel saving
- Reduced CO2 emission rates.
The principle of Micro-hybrid (Start-Stop) idea is avoiding combustion of fuel when there is no need for fuel. Quantity of fuel consumed for starting the engine and 0,7 second of idling is same in either case.In case of idling more than 0,7 second, this technology will ensure a fuel saving of up to 10% in vehicles with regenerative braking system and up to 5% in other vehicles.
Technical Features
- Totally sealed double-lid Patented design which meets most challenging leak-proof requirements and passed 180º roll-over test
- Special labyrinth plugs
- Flame arresters inside the lid
- Charge level indicator on the lid
- Special terminal covers and user friendly handle
- Full-frame positive plates
- Special separators with low internal resistance
- Special paste formula prepared by using Nano Crystal Technology
- Special alloy with improved corrosion-resistance at higher temperatures
- Maximum acid reserve capacity over the plates
Benefits
- Ready-to-use, totally maintenance-free
- More safe with f lame arresters
- 2,5 times more cycle life compared to standard lead-acid batteries
- %15 more starting power than the standard batteries
Nanocrystal Technology
- The paste produced through a special process ensures a homogeneous structural dispersal, increased active material adhesion to the grid, and 2,5 times more cycle life compared to standard lead acid batteries.
- It offers high performance with perfect crystal structure formation and porous paste structure by addition of special chemical materials.
Full Frame Cast Grids
- Resistant special-alloy lead enabling corrosion resistance at high temperatures
- Minimum loss of water thanks to its special alloy
- Minimum self-discharge
- Special grid design ensuring maximum passage of current and high starting power
- Thicker grids
Special SeparatorsOptimised special separators used for plates:
- Maximum hold of active material
- Minimised short-circuit risk
- Reduced electrical internal resistance to provide higher starting power
- Advanced structure ensuring loss of water 20% less than that of standard batteries
- 40% greater oxidation resistance
Maximum Acid Reserve CapacityOptimised design provides more acid reserve capacity over the plates in the box. High acid reserve capacity:
- Reduces corrosion
- Provides longer life
- Improves battery performance
Storage & Installation
Wet Batteries
Always store in a dry and cool place in the upright position. (10°C to 25°C). Place batteries on a wood pallet for avoiding direct contact with concrete ground.
A) Check the Charge Level of your Battery Periodically (Every 3 months)
- Charge level of the battery must be greater than 12,6V before sale.
- During storage, the minimum voltage must be 12,4V. Otherwise, any lower voltage rate will result in sulphating of plates leading to reduced battery performance. For preventing any permanent damage, unpack the battery and charge at 16,1V and 1/20Cn current (1/20 of Ampere rate) without undue delay.
B) Employ FIFO (First-In First-Out) Method for your Inventories
The first batteries entered into the inventory are the first ones to be sold. Please check that the battery ensures the conditions specified in Article A.
C) Battery Installation
- Before installation, make sure that battery to be installed in your car is correct by referring to operating manual of your car.
- Make sure that the engine is switched off.
- Remove the old battery first by releasing from the negative terminal cable, and then the positive terminal cable.
- When the vehicle engine is off, conduct a short-circuit control to make sure whether there is any electric consumption (conduct a leakage test).
- Clean the battery compartment and terminal connections by using a brush, and replace them if necessary.
- Install the new battery. Avoid tightening the bottom connections too tight. Before performing the connection, check the polarity starting from the positive cable. Clean the terminals using vaseline. Negative cable must always be connected in the end. Tighten the connections so that they are not loose.
- When the engine is on, check the compatibility of charge current by controlling the voltage at battery terminals. After installing the new battery in your car, gear up the vehicle in order to check whether the alternator voltage output rate specified in vehicle manual is compatible with the electric system.
Health & SafetySulphuric acid in the battery is very harmful.
Measures:
- Always carry the batteries carefully
- Always keep in the upright position
- Charge in a well-ventilated place
Do not add extra quantities of pure water. (Pure water level must not be more than 1.5 cm above the plates.) During battery maintenance (addition of water, cleaning, battery charge), absolutely wear protective goggles suitable with working conditions. In case of any possible acid splash risk, wear protective clothing.
Emergency:
- In case of contact with eyes or skin wash with plenty of water
- Immediately remove contaminated clothing
- Ingestion: Drink plenty of water and milk, consult a physician
- Spill: Wash small-spills with water
- Operating batteries emit highly flammable hydrogen and oxygen gases
- Do not smoke or avoid any sources and acts which may cause sparks near batteries which are being charged, operating on the vehicle, or stopped after a long operation period, keep fire away
- Use all devices with great care
