The Xmitter Prime Double Stack LED Bar achieves the farthest lighting distance in the Vision X line up. This is due to the 3-watt LEDs that are placed much closer together on the circuit board than 10-watt LEDs allowing for greater optical control and therefore greatest distance. The Xmitter Prime also makes use of Prime Drive Technology which manages heat levels to prolong the life of the LEDs. The Xmitter Prime Double Stack adds 2 more rows of LEDs in the same length for 2x the light.

Features

• Integrated Electronic Thermal Management (ETM)
• New Generation LED is driven to 90% Efficiency
• Defined Optics Optimize Distance and Depth
• Advanced Heat Sink Designed to prolong the life of the LEDs

Prime Drive - The Smart LED Bar

Electronic Thermal Management

ETM monitors the heat output of the LEDs and makes use of integrated Pulse Width Modulation circuitry in order to maintain safe operating temperatures in order to prolong the LED life span to its full 50,000 hour potential.

Pulse Width Modulation

The Xmitter Prime utilizes integrated Pulse Width Modulation (PWM) dimming circuitry to manage heat levels. PWM works by flashing the LED at a frequency faster than the human eye can detect, reducing the time that the LED is operating while still delivering 100% light output.

Bold, Strong Design- The Tough LED Bar

Extruded 6061 Aluminum

The Xmitter Prime is housed in 6061 extruded aluminum for ultimate strength and durability.

IP-68 Rated

The Xmitter Prime has achieved an ingress protection rating of IP-68, signifying that it is dust-proof and submersible in water up to 3 m...

Read more [+]

The Xmitter Prime Double Stack LED Bar achieves the farthest lighting distance in the Vision X line up. This is due to the 3-watt LEDs that are placed much closer together on the circuit board than 10-watt LEDs allowing for greater optical control and therefore greatest distance. The Xmitter Prime also makes use of Prime Drive Technology which manages heat levels to prolong the life of the LEDs. The Xmitter Prime Double Stack adds 2 more rows of LEDs in the same length for 2x the light.

Features

• Integrated Electronic Thermal Management (ETM)
• New Generation LED is driven to 90% Efficiency
• Defined Optics Optimize Distance and Depth
• Advanced Heat Sink Designed to prolong the life of the LEDs

Prime Drive - The Smart LED Bar

Electronic Thermal Management

ETM monitors the heat output of the LEDs and makes use of integrated Pulse Width Modulation circuitry in order to maintain safe operating temperatures in order to prolong the LED life span to its full 50,000 hour potential.

Pulse Width Modulation

The Xmitter Prime utilizes integrated Pulse Width Modulation (PWM) dimming circuitry to manage heat levels. PWM works by flashing the LED at a frequency faster than the human eye can detect, reducing the time that the LED is operating while still delivering 100% light output.

Bold, Strong Design- The Tough LED Bar

Extruded 6061 Aluminum

The Xmitter Prime is housed in 6061 extruded aluminum for ultimate strength and durability.

IP-68 Rated

The Xmitter Prime has achieved an ingress protection rating of IP-68, signifying that it is dust-proof and submersible in water up to 3 meters.

Proven Mounting System

The Xmitter Prime utilizes the Vision X signature stud mounting system that allows for 15° of adjustability and helps to control vibration through the use of isolated rubber in the mount.



Read less [-]
