SPL 100.2 is a Tec stereo 2 channel amplifier 2 x 120.
Features
Specifications
Features
- 2 channel power amplifier
- 2 ohm stable MOSFET amplifier design
- PWM MOSFET Power Supply
- Accurate stated amplifier technology
- Variable high-pass crossover (40Hz-600Hz)
- Variable low-pass crossover (40Hz-600Hz)
- Variable bass-boost 18dB at 45Hz
- O gauge power and ground connections
- Silver plated audio input connections
- Silver plated RCA output for multi-amp installations
Specifications
- Into 4 ohm stereo 120W X 2CH
- Into 2 ohm stereo 200W X 2CH
- Into 4 ohm stereo 380W X 1CH
- Recommended fuse size: 2 X 25A AMP ATO
- Heatsink dimensions: 300(L) X 245(W) X 49(H)
- Frequency response: 3dB 5Hz TO 38KHz
- Signal to noise ratio: >95dB
- T.H.D: 0.05
- Signal input sense: 300 millivolts to 8 volts
- LP variable X-over: 40Hz TO 600Hz @18dB/octave
- HP variable X-over: 40Hz TO 600Hz @18dB/octave
- Variable bass boost: 18dB at 45Hz
- Minimum load stability: 2 ohm stereo/4 ohm bridged
|
|
||||||||||||||||||||||||||||||||||
